1700 Wood Insert


Call 800-665-1411 or submit details below for pricing.

Description

Like its larger counterpart Osburn 2000, the 1700 insert offers a revamped version of perfect size to provide ambiance and warmth. Give yourself a real haven of peace with an eco-friendly device whose average particle emission rate is prodigiously low at 1.26 g/h!

Inside and out, this insert is engineered from high quality materials that put you at the center of a heating experience for many years: high-density bricks, cast iron door and quiet blower for increased durability. Discover the different options to customize the look of your appliance, available in black or brushed nickel plated: door overlays, faceplates and faceplate trims.

Appliance Performance

Fuel type : Dry cordwood
Recommended heating area-ft² : () 500 - 1,800
Overall firebox volume : 1.9
EPA loading volume-ft³ : 1.44
Maximum burn time : () 6 h
Maximum heat output (dry cordwood) :  65,000 BTU/h (19 kW)
Overall heat output rate < : 15,650 BTU/h (4.6 kW) to 23,300 BTU/h (6.83 kW)
Average overall efficiency (EPA cribs/Douglas fir) :  N.A. (HHV)  N.A. (LHV)
Average overall efficiency (dry cordwood) :  70 % (HHV) 75 % (LHV)
Optimum efficiency :  78 %
Average particulate emissions rate : 1.26 g/h
Average CO : 58 g/h

General Features

Combustion technology Non-catalytic
High-efficiency certified appliance Yes, EPA 2020 approved
Maximum log length 18"
Log positioning Loading over width
Chimney diameter 6"
Flue outlet diameter 6"
Type of chimney Liner - ULC-S635, CAN/ULC-S640, UL1777
Minimum chimney height (feet) 15'
Baffle type C-Cast
Approved for a mobile home installation No
Shipping Weight 361 lb (164 kg)
Door type Single, glass with cast iron frame
Glass type Ceramic glass
Glass surface – dimensions (Width X Height) 15 3/4" x 9 3/8"
Glass air-wash system Yes
Premium quality blower included (CFM) 144
Overall dimension (Height) 21 1/4"
Overall dimension (Width) 27 1/8"
Overall dimension (Depth) 22 3/8"
Door opening – dimension (Height) 8 3/4"
Door opening - dimension (Width) 17 1/4''
Firebox – dimension (Height) 11 7/8"
Firebox – dimension (Width) 19 5/8"
Firebox – dimension (Depth) 13 1/2"
Firebox lined with refractory bricks for better heat distribution Yes
Stainless-steel secondary-air system improving gas combustion Yes
Adjustable threaded legs Yes
Steel thickness – body 3/16"
Steel thickness – top 5/16"
Fireplace opening – minimum (Height) 21 1/2"
Fireplace opening – minimum (Width) 27 1/2"
Fireplace opening – minimum (Depth) 12 7/8"
USA standard (emissions) EPA
Canadian Standard (emissions) CSA B415.1-10
USA standard (safety) UL 1482, UL 737
Canadian standard (safety) ULC S628
Tested and listed as per applicable standards By an accredited laboratory (CAN/USA)
Warranty Limited lifetime
